WKG - Whirl massage device for upper limbs
Whirl massage device type WKG is designed for hydrotherapy performed by means of a stream of water generated by a pump. Whirl massage results in hyperemia, decreased oedema, reduced venous blood stasis, accompanied by analgesic effect and muscles relaxation. For use in professional medical care facilities, such as hospitals, clinics, etc.
Product photos on the website are for reference only. They may differ slightly from the actual product. Manufacturer hereby reserves the right to change design that would not disturb the principal functionality and safety requirements.
WKG - Whirl massage device for upper limbs
Whirl massage device type WKG is designed for hydrotherapy performed by means of a stream of water generated by a pump. Whirl massage results in hyperemia, decreased oedema, reduced venous blood stasis, accompanied by analgesic effect and muscles relaxation. For use in professional medical care facilities, such as hospitals, clinics, etc.
Features:
Basin available in two colours: white or calypso green
Basin made of acrylic (fibreglass mat reinforced)
Use of water – min. 30 l (all nozzles immersed)
Whirl massage via 44 nozzles
„Dry-run" pump protection system
Adjustable air supply system for the nozzles
Electronically controlled descaling system
Electronic control panel
Treatment time: max. 30 min
Temperature sensor
Water level sensor
Emptying by the means to drain knob
Shower head
Big diameter drain and filling system
Automatic filling (optional)
The device is sold together with the chair.
Dimensions: (width x height) of the seat 460 x 420 mm, backrest 400 x 290 mm.
Seat height adjustment: using a pneumatic lift with a stroke of 190 mm in the range of 450-640 mm.
The base of the chair with a diameter of 580 mm is made of polyamide reinforced with glass fiber.
The CPT mechanism, which connects the seat with the backrest, allows you to adjust the angle of the backrest to the seat, allows you to raise the backrest, and adjust the distance of the backrest from the seat.
Technical Data:
| Min. working capacity [l]: | 30 |
| Max. working capacity (up to overflow) [l]: | 45 |
| Number of aeration nozzles: | 44 |
| Current consumption [A]: | 5 |
| Filling (up to overflow) / emptying [s]: | 76 / 42 |
| Power supply [V/Hz]: | 230/50 |
| Dimenssions (L x W x H) [cm]: | 90 x 95 x 92 |
| Protection class, applied part: | Class I, Type B |
| Weight [kg]: | 60 |
Video presentation:
Update: 08-10-2024, time 13:28
