WKG - Whirl massage device for upper limbs

The WKG - Whirl Massage Device is designed for hydrotherapy using a stream of water generated by a pump. This whirl massage promotes hyperemia, reduces edema, alleviates venous blood stasis, and provides analgesic effects while relaxing muscles. It is intended for use in professional medical care facilities, such as hospitals and clinics.

Producer: Meden-Inmed

Medical device: Medical component

Color:

Additional Options:

Product photos on the website are for reference only. They may differ slightly from the actual product. Manufacturer hereby reserves the right to change design that would not disturb the principal functionality and safety requirements.

WKG - Whirl massage device for upper limbs

The WKG whirl massage device is designed for hydrotherapy treatments using a stream of water generated by a pump. This whirl massage promotes hyperemia, reduces edema, alleviates venous blood stasis, and provides analgesic effects along with muscle relaxation. It is intended for use in professional medical facilities, including hospitals, clinics, and other healthcare settings.

WKG - Whirl massage device for upper limbs
WKG - Whirl massage device for upper limbs

Features:

Basin is available in two colors: white or calypso green

Basin made of acrylic (fibreglass mat reinforced)

Water usage – minimum 30 liters (to fully immerse all nozzles)

Whirl massage is provided through 44 nozzles

„Dry-run" pump protection system

Adjustable air supply system for the nozzles

Electronically controlled descaling system

Electronic control panel

Maximum treatment time: 30 minutes

Temperature sensor

Water level sensor

Emptying via drain knob

Shower head

Big diameter drain and filling system

Automatic filling (optional)

The device is sold together with the chair.

Seat dimensions: (width x height): 460 x 420 mm.

Seat height adjustment: Pneumatic lift with a stroke of 190 mm, adjustable within the range of 450-640 mm.

Chair Diameter of 580 mm, made of polyamide reinforced with glass fiber

CPT mechanism Connects the seat to the backrest, allowing angle adjustment between the seat and backrest, as well as raising the backrest and adjusting the distance between the backrest and seat.

WKR

Technical Data:

Min. working capacity [l]: 30
Max. working capacity (up to overflow) [l]: 45
Number of aeration nozzles: 44
Current consumption [A]: 5
Filling (up to overflow) / emptying [s]: 76 / 42
Power supply [V/Hz]: 230/50
Dimenssions (L x W x H) [cm]: 90 x 95 x 92
Protection class, applied part: Class I, Type B
Weight [kg]: 60
