Levitop Standard - Mobile patient lift
Mobile patient lift Levitop Standard makes it easier to raise and transport patients with disabilities and with reduced mobility.
Product photos on the website are for reference only. They may differ slightly from the actual product. Manufacturer hereby reserves the right to change design that would not disturb the principal functionality and safety requirements.
Levitop Standard - Mobile patient lift
The Levitop Standard lift is a mobile lift designed to assist individuals with reduced mobility due to illness or dysfunction. The lift is sleek and fast, providing efficient and safe repositioning. It can lift and transport patients from a rehabilitation bed, bathtub or shower tray, or even directly from the floor with the appropriate suspension.
The battery has a large capacity and can perform approximately 20 full lifting and lowering cycles on a single charge, with a maximum load of 230 kg.
Features:
The lift is equipped with a four-point sling as standard,
the sling rotates 360o with the possibility of locking in four positions (90o),
wheels allowing maneuvering even in small and narrow spaces,
rear wheels equipped with a brake,
Remote control included,
adjustment of the width of the leg span with the remote control,
possibility to lift the patient directly from the floor,
emergency lowering mechanism to increase patient safety.
Levitop Standard will be an excellent choice for:
Hospital
Developed for use in hospitals, the innovative Levitop Standard mobile patient lift is an indispensable tool to support the patient care process. The use of this advanced device brings numerous benefits to both medical personnel and patients.
Care home
Levitop Standard - Mobile patient lift is an invaluable aid for medical staff and patients in the sanatorium environment. With its advanced features and ergonomic design, it enables effective and safe movement of people with various health needs in rehabilitation therapy.
Private usage
Levitop Standard - Mobile patient lift is an indispensable tool for home use, providing support and safety during daily activities. Thanks to its use, it is possible to effectively and comfortably lift and move people with limited mobility.
Sanatorium
Levitop Standard - Mobile patient lift is an invaluable aid for medical staff and patients in the sanatorium environment. With its advanced features and ergonomic design, it enables effective and safe movement of people with various health needs in rehabilitation therapy.
VertiUp eFlow drive system
It consists of two main parts: the drive system and the steering handle. The drive wheel is located between the two castors at the bottom of the lift. The steering handle mimics the operator's movements thanks to built-in sensors. The drive system, powered by LINAK's lithium-ion battery, drives the lift with minimal effort. The drive system allows the lift to be moved in any direction with minimal effort. As a result, control of the lift is intuitive and independent of the weight of the patient and the lift itself.
Very sensitive sensors ensure that the lift moves smoothly and is easy to manoeuvre in tight spaces. If the hand is removed from the handle (control rail), the built-in electromagnetic brake stops the unit in a short time.
Advatages of Levitop Standard
Sling strap
Rotatable 360°
Strong construction
Frame made of durable metal
Robust suspension attachment
For lifting arms
Remote controller
Ergonomic and easy to use
Braked wheels
Brakes in the rear wheels prevent the unit from moving during use
Suspension lock
Blocking the rotation of the beam
Universal
- Head support: yes
- Material: polyester
- Sizes: M, L, XL, bariatric
- Lifting capacity: 318 kg / 454 kg
- Attachment: loops
Bath & Toilet
- Head support: yes
- Material: polyester mesh
- Sizes: M, L, XL
- Lifting capacity: 250 kg
- Attachment: loops
Bath & Toilet
- Head support: no
- Material: polyester mesh
- Sizes: M, L, XL
- Lifting capacity: 250 kg
- Attachment: clips
Technical data:
| Base legs spreading: | electrical |
| Max. safe working load (SWL)[kg]: | 230 |
| Lenght [cm]: | 130 |
| Width [cm]: | 67 |
| Height [cm]: | 135 |
| Lifting range [cm]: | 68 - 196 |
| Min. turning diameter [cm]: | 144 |
| Min. base legs width (int./ext.) [cm]: | 52 / 67 |
| Max. base legs width (int./ext.) [cm]: | 103 / 118 |
| Base legs height [cm]: | 11,5 |
| Wheels diameter (without / with lock) [cm]: | 10 / 12,5 |
| Weight [kg]: | 61 |
| Battery capacity [Ah]: | 2,9 |
| Charger (integrated with control box) [V/Hz]: | 100-240 / 50 / 60 |
| Remote control functions: |
|
| Lifting speed (raising / lowering) [s]: | 36 / 34 |
| Packed dimensions (L x W x H) [cm]: | 150 x 80 x 155 |
Video presentation:
Update: 06-11-2024, time 13:46
Levitop Standard - Mobile patient lift
